FOCUS MWBZ serial stabilized soil mixing station own the following characteristics: Main machine adopts double horizontal continuous non-lining mixer, with convenient maintenance, uniform mixing and high productivity. Batching system adopts electronic weighing or volume weighing, with reliable and accurate weighing and quick speed of changing matching. Computer control technology can carry out the whole process management, which manual and automatic choice, convenient operation and good reliability.
Speed regulation adopts international advanced variable frequency speed control and electromagnetic speed control, with energy-saving and stepless speed regulation, which completely ensure the reliability of equipment running. Water supply adopts intelligent turbine flowmeter, with accurate metering and direct display. Plus, there are 2-20 tons sacked cement silos and 40-100 tons bulk cement silo to meet the customers requirements.
Please fill below form if need quotation or support, we will get back to you as soon as possible.
Speed regulation adopts international advanced variable frequency speed control and electromagnetic speed control, with energy-saving and stepless speed regulation, which completely ensure the reliability of equipment running. Water supply adopts intelligent turbine flowmeter, with accurate metering and direct display. Plus, there are 2-20 tons sacked cement silos and 40-100 tons bulk cement silo to meet the customers requirements.
Please fill below form if need quotation or support, we will get back to you as soon as possible.
Click to enlarge the form
model parameter |
MWCB300 | MWCB400 | MWCB500 | MWCB600 |
---|---|---|---|---|
Production capacity | 300tons/h | 400tons/h | 500tons/h | 600tons/h |
Maximum size of aggregate | 60mm | 60mm | 60mm | 60mm |
Aggregate weighing accuracy | 2% | 2% | 2% | 2% |
Cement weighing accuracy | 1% | 1% | 1% | 1% |
Water weighing accuracy | 1.5% | 1.5% | 1.5% | 1.5% |
Aggregate storage bin capacity | 4×10m3 | 4×10m3 | 4×10m3 | 4×10m3 |
Mixed material storage bin capacity | 5m3 | 5m3 | 5m3 | 5m3 |
Cement silo | 80 tons | 100 tons | 100 tons | 100 tons |
Power | 98kw | 118kw | 150kw | 168kw |
Total weight | 32 tons | 35 tons | 40 tons | 51 tons |
Control mode | Auto/Manual | Auto/Manual | Auto/Manual | Auto/Manual |
