HINO Chassis Concrete Truck Mixer for Sale---[2018-05-24] We have five units of well-fabricated truck mixer with imported HINO chassis on sales. The promotional price is lower than our current costs, any client who is interested please contact us ASAP. The technical information are as follows:

Overall Dimension Parameter	Items	CLGTM308E	Net Weight	13700kg
	Total length	9000 (mm)	Loading Weight	19200kg
	Total width	2496 (mm)	GVW	32900kg
	Total height	3850(mm)
Chassis	Chassis manufacturer	GAC HINO MOTORS	Chassis Engine Power	259 KW
	Chassis Emission	Euro III
Specifications	Drum Geometrical Volume(m 3)	14.6	Hydraulic System Pressure (MPA)	42
	Drum Agitating Capacity（m3）	8	Drum Inclined Angle（°ï¼‰	12.5
	Concrete Charge Speed（m3/min）	≥3	Hydraulic Reservoir Capacity (L)	20
	Concrete Discharge Speed（m3/min）	≥2.7	Mixer Body Weight(kg)	4,000
	Drum Remnant Ratio（%）	≤0.5	Water Reservoir Capacity (L)	450
	Drum Revolution(r/min)	0 - 14	Water Supply Type	Pneumatic Pressure
Item		Standard configuration		Optional
Hydraulics	Hydraulic Pump		DANFOSS	REXROTH
	Hydraulic Motor		DANFOSS	REXROTH
